Rama: 800 Series OCLV Carbon, KVF (Ka mmtail Virtual Foil) tube shape, IsoFlow seat tube, invisible cable routing, 3S aero chain keeper, T47 BB, flat mount disc, 142×12 mm thru axle
Prednja vilica: Madone KVF full carbon, tapered carbon steerer, internal brake routing, flat mount disc, carbon dropouts, 12×100 mm thru axle
Kotači: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100×12 mm thru axle, Shimano 11/12-speed freehub, 142×12 mm thru-axle
Gume: Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700×25 mm
Ručice mjenjača: Shimano Ultegra R8170 Di2, 12-speed
Prednji mjenjač: Shimano Ultegra R8150 Di2, braze-on, down swing
Zadnji mjenjač: Shimano Ultegra R8150 Di2, 34T max cog
Pogon: Shimano Ultegra R8100, 52/36
Osovina pogona: Praxis, T47 threaded, internal bearing
Kazeta: Shimano Ultegra R8100, 11-30, 12 speed
Lanac: Shimano Ultegra/XT M8100, 12-speed
Sjedalo: Bontrager Aeolus Elite, austenite rails
Cijev sjedala: Madone aero carbon internal seat mast cap, integrated light mount, 0 mm offset, tall length (Size 47, 50, 52, 54: short length; Size: 56, 58, 60, 62: tall length)
Kormilo: Madone Integrated handlebar/stem, OCLV Carbon
Navlake kormila: Bontrager Supertack Perf tape
Lula kormila: Trek Madone aero, invisible cable routing, 7 degree
Kočnice: Shimano Ultegra hydraulic disc, BR-R8170 flat mount caliper
Težina: 56 – 7.48 kg / 16.51 lbs
