Rama: Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew (Size XS: curved top tube)
Prednja vilica: RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel (Size XS, S: 42 mm offset for 27.5″ wheel, 100 mm travel)
Prednja glavčina: Formula DC-20, alloy, 6-bolt, 5×100 mm QR
Zadnja glavčina: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR
Obruči: Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Žbice: 14 g stainless steel
Gume: Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29×2.35″ (Size XS & S: Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5×2.35”)
Ručice mjenjača: Shimano U6000, 10-speed
Zadnji mjenjač: Shimano CUES U6000 GS
Pogon: Shimano U4000, 30T chainring, 175 mm length (Size: XS, S, M, M/L: 170 mm length)
Osovina pogona: Shimano, 73 mm, threaded cartridge, 122.5 mm spindle
Kazeta: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Lanac: Shimano LG500
Pedale: VP-536 nylon platform
Sjedalo: Bontrager Verse Short, stainless steel rails
Cijev sjedala: TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length (Size: XS , S: 350 mm length; Size: M: 405 mm length; Size: XXL: 500 mm length)
Kormilo: Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width (Size: XS: 5mm rise, 690 mm width; Size: S: 15mm rise, 720 mm width)
Navlake kormila: Trek Line Comp, nylon lock-on
Lula kormila: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length (Size XS, S: 35 mm length; Size M, M/L, L: 50 mm length; Size XL: 60 mm length)
Garnitura vilice: Semi-integrated, 1-1/8″
Kočnice: Shimano MT200 hydraulic disc
