Rama: OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel
Prednja vilica: RockShox Recon Gold RL, DebonAir spring, Motion Control damper, remote lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Zadnja suspenzija: Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position damper, 235×32.5mm
Prednja glavčina: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Zadnja glavčina: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Obruči: Bontrager Kovee Comp, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Gume: Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29×2.20″
Ručice mjenjača: Shimano Deore M6100, 12-speed
Zadnji mjenjač: Shimano SLX M7100, long cage
Pogon: Shimano MT511, 32T steel ring, 52 mm chainline
Osovina pogona: Shimano MT500, 92 mm, PressFit
Kazeta: Shimano Deore M6100, 10-51, 12-speed
Lanac: Shimano Deore M6100
Sjedalo: Bontrager Arvada, steel rails, 138 mm width
Cijev sjedala: Bontrager Comp, 6061 alloy, 31.6 mm, 8 mm offset
Kormilo: Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width
Navlake kormila: Bontrager XR Trail Comp, nylon lock-on
Lula kormila: Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree
Garnitura vilice: Knock Block Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom
Kočnice: Shimano hydraulic disc, MT4100 lever, MT410 calliper
